Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Mounting Type	Coil Voltage	Operating Temperature	Termination Style	Coil Current	Contact Material	Contact Form	Contact Rating (Current)	Switching Voltage	Must Release Voltage	Must Operate Voltage	Operate Time	Release Time	Coil Power	Coil Resistance
RF1V-4A2BLD1-D12 RELAY GEN PURPOSE 6PST 6A 24V IDEC Datasheet	23 In Stock	1 : $45.65 10 : $433.70 100 : $3,652.00 Bulk	RF1V	Bulk	Active	Diode, Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	20.8 mA	Silver Tin Oxide (AgSnO)	6PST-4NO/2NC (4 Form A, 2 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	500mW	1.15 kOhms
RF1V-3A1BLD1-D24 RELAY GEN PURPOSE 4PST 6A 24V IDEC Datasheet	100 In Stock	1 : $42.78 10 : $406.40 100 : $3,423.00 Bulk	RF1V	Bulk	Active	Diode, Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	4PST-3NO/1NC (3 Form A, 1 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
RF1V-5A1B-D24 RELAY GEN PURPOSE 6PST 6A 24V IDEC Datasheet	514 In Stock	1 : $20.82 10 : $197.80 25 : $468.50 50 : $916.50 Bulk	RF1V	Bulk	Active	-	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	6PST-5NO/1NC (5 Form A, 1 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
RF1V-4A2BLD1-D24 RELAY GEN PURPOSE 6PST 6A 24V IDEC Datasheet	29 In Stock	1 : $45.65 10 : $433.70 100 : $3,652.00 Bulk	RF1V	Bulk	Active	Diode, Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	6PST-4NO/2NC (4 Form A, 2 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
HR6S-AF1P SAFETY RELAY MOD CAT.4 SAF SCREW IDEC Datasheet	34 In Stock	1 : $274.24 10 : $2,581.10 Bulk	HR6S	Bulk	Active	-	DIN Rail	24VAC/DC	-	Screw Terminal	-	-	3PST-NO (3 Form A)	6 A	250VAC, 24VDC - Max	-	-	-	-	-	-
RF1V-3A1B-D24 RELAY GEN PURPOSE 4PST 6A 24V IDEC Datasheet	65 In Stock	1 : $24.40 10 : $231.80 100 : $1,952.00 Bulk	RF1V	Bulk	Active	-	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	4PST-3NO/1NC (3 Form A, 1 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
RF1V-5A1BL-D24 RELAY GEN PURPOSE 6PST 6A 24V IDEC Datasheet	1,005 In Stock	1 : $33.49 10 : $318.20 25 : $753.50 50 : $1,423.50 100 : $2,679.00 250 : $6,280.00 Bulk	RF1V	Bulk	Active	Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	20.8 mA	Silver Tin Oxide (AgSnO)	6PST-5NO/1NC (5 Form A, 1 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	500mW	1.15 kOhms
RF1V-2A2BL-D24 RELAY GEN PURPOSE 4PST 6A 24V IDEC Datasheet	296 In Stock	1 : $28.30 10 : $268.90 25 : $636.75 50 : $1,203.00 100 : $2,264.00 250 : $5,307.50 500 : $9,905.00 Bulk	RF1V	Bulk	Active	Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	4PST-2NO/2NC (2 Form A, 2 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
RF1V-5A1BLD1-D24 RELAY GEN PURPOSE 6PST 6A 24V IDEC Datasheet	44 In Stock	1 : $45.65 10 : $433.70 25 : $1,027.25 50 : $1,940.00 100 : $3,652.00 250 : $8,560.00 Bulk	RF1V	Bulk	Active	Diode, Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	6PST-5NO/1NC (5 Form A, 1 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
RF1V-2A2BLD1-D24 RELAY GEN PURPOSE 4PST 6A 24V IDEC Datasheet	3 In Stock	1 : $42.78 10 : $406.40 25 : $962.75 50 : $1,818.50 100 : $3,423.00 250 : $8,022.50 Bulk	RF1V	Bulk	Active	Diode, Lighted Indicator	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	-	Silver Tin Oxide (AgSnO)	4PST-2NO/2NC (2 Form A, 2 Form B)	6 A	250VAC, 30VDC - Max	2.4 VDC	18 VDC	20 ms	20 ms	-	-
