Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Output Type	Mounting Type	Operating Temperature	Voltage - Supply	Voltage - Forward (Vf) (Typ)	Data Rate	Input Type	Voltage - Isolation	Current - DC Forward (If) (Max)	Inputs - Side 1/Side 2	Supplier Device Package	Rise / Fall Time (Typ)	Common Mode Transient Immunity (Min)	Propagation Delay tpLH / tpHL (Max)	Grade	Number of Channels	Current - Output / Channel	Qualification
PS2561L-1-V-F3-W-A OPTOISOLATOR 5KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	2,000 : $500.00 6,000 : $1,500.00 10,000 : $2,400.00 Tape & Reel (TR)	NEPOC	Tape & Reel (TR)	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.17V	-	DC	5000Vrms	-	-	4-SMD	3µs, 5µs	-	-	-	1	-	-
PS2801A-1-V-F3-M-A OPTOISOLATOR 2.5KV TRANS 4SOIC CEL (California Eastern Laboratories) Datasheet	0 In Stock	Discontinued	NEPOC	Tape & Reel (TR)	Discontinued	4-SOIC (0.173", 4.40mm Width)	Transistor	Surface Mount	-55°C ~ 100°C	-	1.2V	-	DC	2500Vrms	-	-	4-SSOP	5µs, 7µs	-	-	-	1	-	-
PS2701-1-V-A OPTOISOLATOR 3.75KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	Discontinued	NEPOC	Tube	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.1V	-	DC	3750Vrms	-	-	4-SMD	3µs, 5µs	-	-	-	1	-	-
PS2565L-1-F3-A OPTOISOLATOR 5KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	2,000 : $560.00 6,000 : $1,620.00 10,000 : $2,700.00 Tape & Reel (TR)	NEPOC	Tape & Reel (TR) Cut Tape (CT)	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.17V	-	AC, DC	5000Vrms	-	-	4-SMD	3µs, 5µs	-	-	-	1	-	-
PS2861-1-F3-K-A OPTOISOLATOR 2.5KV TRANS 4SOIC CEL (California Eastern Laboratories) Datasheet	0 In Stock	Obsolete	NEPOC	Tape & Reel (TR)	Obsolete	4-SOIC (0.173", 4.40mm Width)	Transistor	Surface Mount	-55°C ~ 100°C	-	1.1V	-	DC	2500Vrms	-	-	4-SOP	4µs, 5µs	-	-	-	1	-	-
PS2701-1-F3-P-A OPTOISOLATOR 3.75KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	3,500 : $735.00 7,000 : $1,400.00 10,500 : $1,995.00 24,500 : $4,655.00 Tape & Reel (TR)	NEPOC	Tape & Reel (TR)	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.1V	-	DC	3750Vrms	-	-	4-SMD	3µs, 5µs	-	-	-	1	-	-
PS2701-1-V-F3-H-A OPTOISOLATOR 3.75KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	3,500 : $840.00 7,000 : $1,610.00 10,500 : $2,415.00 24,500 : $5,390.00 Tape & Reel (TR)	NEPOC	Tape & Reel (TR)	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.1V	-	DC	3750Vrms	-	-	4-SMD	3µs, 5µs	-	-	-	1	-	-
PS2701A-1-F3-P-A OPTOISOLATOR 3.75KV TRANS 4SMD CEL (California Eastern Laboratories) Datasheet	0 In Stock	3,500 : $630.00 7,000 : $1,190.00 10,500 : $1,680.00 24,500 : $3,920.00 Tape & Reel (TR)	NEPOC	Tape & Reel (TR)	Discontinued	4-SMD, Gull Wing	Transistor	Surface Mount	-55°C ~ 100°C	-	1.2V	-	DC	3750Vrms	-	-	4-SOP	5µs, 7µs	-	-	-	1	-	-
PS7160L-1A-E3-A SSR RELAY SPST-NO 90MA 0-600V CEL (California Eastern Laboratories) Datasheet	0 In Stock	Obsolete	PS, OCMOS	Tape & Reel (TR)	Obsolete	6-SMD (0.300", 7.62mm)	AC, DC	Surface Mount	-	-	-	-	-	-	-	-	6-DIP Gull Wing	-	-	-	-	-	-	-
PS2801A-1-L-A OPTOISOLATOR 2.5KV TRANS 4SOIC CEL (California Eastern Laboratories) Datasheet	0 In Stock	550 : $242.00 Tube	NEPOC	Tube	Discontinued	4-SOIC (0.173", 4.40mm Width)	Transistor	Surface Mount	-55°C ~ 100°C	-	1.2V	-	DC	2500Vrms	-	-	4-SSOP	5µs, 7µs	-	-	-	1	-	-
