Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Mounting Type	Coil Voltage	Operating Temperature	Termination Style	Coil Current	Coil Type	Contact Material	Contact Form	Contact Rating (Current)	Switching Voltage	Must Release Voltage	Must Operate Voltage	Operate Time	Release Time	Coil Power	Coil Resistance
RT214048 RELAY GEN PURPOSE SPDT 12A 48V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	Obsolete	RT1, SCHRACK	Tube	Obsolete	-	Through Hole	48VDC	-40°C ~ 85°C	PC Pin	14.2 mA	Non Latching	Silver Nickel (AgNi)	SPDT (1 Form C)	12 A	400VAC - Max	4.8 VDC	33.6 VDC	8 ms	6 ms	-	-
RTB14048F RELAY GEN PURPOSE SPDT 12A 48V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	Active	RT1	Tube	Active	-	Through Hole	48VDC	-40°C ~ 85°C	PC Pin	8.7 mA	Non Latching	Silver Nickel (AgNi)	SPDT (1 Form C)	12 A	400VAC - Max	4.8 VDC	33.6 VDC	8 ms	6 ms	-	5.52 kOhms
V23100V4005A010 RELAY REED SPST 500MA 5V TE Connectivity Potter & Brumfield Relays Datasheet	1,249 In Stock	1 : $11.77 10 : $104.60 25 : $248.50 50 : $471.00 100 : $889.00 250 : $2,027.50 500 : $3,795.00 1,000 : $7,190.00 Tube	V23100-V4, AXICOM	Tube	Active	Diode	Through Hole	5VDC	-40°C ~ 85°C	PC Pin	10 mA	Non Latching	Ruthenium (Ru)	SPST-NO (1 Form A)	500 mA	200VAC, 200VDC - Max	0.75 VDC	3.5 VDC	0.75 ms	0.15 ms	-	-
V23100V4312C000 RELAY REED SPDT 250MA 12V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	1,250 : $11,225.00 Tube	V23100-V4, AXICOM	Tube	Discontinued	-	Through Hole	12VDC	-40°C ~ 85°C	PC Pin	24 mA	Non Latching	Ruthenium (Ru)	SPDT (1 Form C)	250 mA	175VDC - Max	1.8 VDC	8.4 VDC	1.1 ms	1.6 ms	-	-
V23100V4324B010 RELAY REED DPST 500MA 24V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	600 : $5,274.00 Tube	V23100-V4, AXICOM	Tube	Discontinued	Diode	Through Hole	24VDC	-40°C ~ 85°C	PC Pin	12 mA	Non Latching	Ruthenium (Ru)	DPST-NO (2 Form A)	500 mA	200VAC, 200VDC - Max	3.6 VDC	16.8 VDC	0.75 ms	0.15 ms	-	-
V23026A1007B201 RELAY GEN PURPOSE SPDT 1A 1.5V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	2,000 : $13,880.00 Tube	V23026, AXICOM	Tube	Active	-	Through Hole	1.5VDC	-40°C ~ 85°C	PC Pin	42 mA	Non Latching	Palladium Nickel (PdNi), Rhodium (Rh), Gold (Au)	SPDT (1 Form C)	1 A	150VAC, 125VDC - Max	0.15 VDC	1.13 VDC	2 ms	2 ms	-	-
7-1393236-1 RELAY GEN PURPOSE SPDT 6A 12V TE Connectivity Potter & Brumfield Relays Datasheet	921 In Stock	1 : $12.75 10 : $113.30 25 : $269.25 50 : $510.00 100 : $963.00 250 : $2,195.00 500 : $4,110.00 1,000 : $7,790.00 Tube	SNR, SCHRACK	Tube	Active	-	Through Hole	12VDC	-40°C ~ 85°C	PC Pin	14.2 mA	Non Latching	Silver Tin Oxide (AgSnO)	SPDT (1 Form C)	6 A	400VAC - Max	0.6 VDC	8.4 VDC	12 ms	5 ms	-	848 Ohms
V23100V4012A011 RELAY REED SPST 500MA 12V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	200 : $2,276.00 Tube	V23100-V4, AXICOM	Tube	Active	Diode, Electrostatic Shield	Through Hole	12VDC	-40°C ~ 85°C	PC Pin	12 mA	Non Latching	Ruthenium (Ru)	SPST-NO (1 Form A)	500 mA	200VAC, 200VDC - Max	1.8 VDC	8.4 VDC	0.75 ms	0.15 ms	-	-
V23100V4315C000 RELAY REED SPDT 250MA 15V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	1,250 : $17,025.00 Tube	V23100-V4, AXICOM	Tube	Active	-	Through Hole	15VDC	-40°C ~ 85°C	PC Pin	7.5 mA	Non Latching	Ruthenium (Ru)	SPDT (1 Form C)	250 mA	175VDC - Max	2.25 VDC	10.5 VDC	1.1 ms	1.6 ms	-	2 kOhms
V23026D1023B201 RELAY GEN PURPOSE SPDT 1A 15V TE Connectivity Potter & Brumfield Relays Datasheet	0 In Stock	2,400 : $15,792.00 Tape & Reel (TR)	V23026, AXICOM	Tape & Reel (TR)	Active	-	Surface Mount	15VDC	-40°C ~ 85°C	Gull Wing	5.3 mA	Non Latching	Palladium Nickel (PdNi), Rhodium (Rh), Gold (Au)	SPDT (1 Form C)	1 A	150VAC, 125VDC - Max	1.5 VDC	11.25 VDC	2 ms	2 ms	-	-
