Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Connector Type	Contact Finish	Current Rating (Amps)	Mounting Type	Number of Positions	Pitch	Style	Operating Temperature	Number of Positions Loaded	Termination	Level, Class	Contact Finish Thickness	Material - Insulation	Material Flammability Rating	Number of Rows
9001-51151AA DIN41612, MALE, H15 TYPE, 15 PIN Oupiin Datasheet	112 Marketplace	1 : $7.35 100 : $686.00 200 : $1,128.00 300 : $1,323.00 400 : $1,276.00 Tray	9001	Tray	Active	-	Header, Male Blades	Silver	15A	Through Hole, Right Angle	15 (Power)	0.200" (5.08mm)	H 15	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	2
9001-12961C00A DIN41612, HALF C TYPE, 96 PIN, R Oupiin Datasheet	1,760 Marketplace	1 : $5.64 100 : $526.00 200 : $864.00 300 : $1,014.00 400 : $976.00 Tray	9001	Tray	Active	-	Receptacle, Female Sockets	Gold	2A	Through Hole	96	0.100" (2.54mm)	C	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	3
9001-12642C00A DIN41612, FEMALE, TYPE C, 64 PIN Oupiin Datasheet	424 Marketplace	1 : $4.53 100 : $423.00 200 : $694.00 300 : $816.00 400 : $784.00 Tray	9001	Tray	Active	-	Receptacle, Female Sockets	Gold	2A	Through Hole	64	0.100" (2.54mm)	C	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	2
9001-16482C00A DIN41612, FEMALE, HALF C TYPE, 4 Oupiin Datasheet	1,470 Marketplace	1 : $3.12 100 : $291.00 200 : $478.00 300 : $561.00 400 : $540.00 Tray	9001	Tray	Active	-	Receptacle, Female Sockets	Gold	2A	Through Hole	48	0.100" (2.54mm)	C/2 (1/2 C)	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	3
9001-16481C00A DIN41612, FEMALE, HALF C TYPE, 4 Oupiin Datasheet	297 Marketplace	1 : $3.12 100 : $291.00 200 : $478.00 300 : $561.00 400 : $540.00 Tray	9001	Tray	Active	-	Receptacle, Female Sockets	Gold	2A	Through Hole	48	0.100" (2.54mm)	C/2 (1/2 C)	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	3
9001-13961C00A DIN41612, MALE, C TYPE, 96 PIN, Oupiin Datasheet	2,240 Marketplace	1 : $3.36 100 : $314.00 200 : $516.00 300 : $606.00 400 : $584.00 Tray	9001	Tray	Active	-	Header, Male Pins	Gold	2A	Through Hole	96	0.100" (2.54mm)	R	-55°C ~ 125°C	All	Solder	-	Flash	Polyester Thermoplastic, Glass Filled	UL94 V-0	3
9001-36322C00L1A DIN41612, FEMALE, HALF B TYPE, 3 Oupiin Datasheet	350 Marketplace	1 : $2.46 Tray	9001	Tray	Active	Board Lock	Receptacle, Female Sockets	Gold	2A	Through Hole	32	0.100" (2.54mm)	B/2 (1/2 B)	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	2
9001-12641C00A DIN41612, FEMALE, C TYPE, 64 PIN Oupiin Datasheet	420 Marketplace	1 : $4.08 100 : $381.00 200 : $626.00 300 : $735.00 400 : $708.00 Tray	9001	Tray	Active	-	Receptacle, Female Sockets	Gold	2A	Through Hole	64	0.100" (2.54mm)	C	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	2
9001-18481C00L1A DIN41612, FEMALE, HALF R TYPE, 4 Oupiin Datasheet	1,134 Marketplace	1 : $3.29 Tray	9001	Tray	Active	Board Lock	Receptacle, Female Sockets	Gold	2A	Through Hole, Right Angle	48	0.100" (2.54mm)	R/2 (1/2 R)	-55°C ~ 125°C	All	Solder	-	Flash	Polybutylene Terephthalate (PBT)	UL94 V-0	3
9001-13641C00A DIN41612, MALE, TYPE R, 64 PIN, Oupiin Datasheet	1,190 Marketplace	1 : $2.67 Tray	9001	Tray	Active	-	Header, Male Pins	Gold	2A	Through Hole	64	0.100" (2.54mm)	R	-55°C ~ 125°C	All	Solder	-	Flash	Polyester Thermoplastic, Glass Filled	UL94 V-0	2
