Mfr Part #	Quantity	Price	Package	Product Status	Package / Case	Mounting Type	Output	Type	Operating Temperature	Voltage - Supply	Current - Quiescent (Iq)	Current - Output High, Low	Supplier Device Package	Max Propagation Delay @ V, Max CL	Output Function	Grade	Number of Bits	Qualification
AM25LS2521/BSA IC COMPARATOR IDENTITY 8B 20CFP Advanced Micro Devices Datasheet	1,391 Marketplace	7 : $335.23 Bulk	Bulk	Active	20-CFlatPack	Surface Mount	-	Identity Comparator	-55°C ~ 125°C	4.5V ~ 5.5V	40 mA	440µA, 12mA	20-CFlatPack	15ns @ 5V, 15pF	-	-	8	-
AM25LS2521PC IC COMPARATOR IDENTITY 8B 20DIP Advanced Micro Devices Datasheet	83,592 Marketplace	141 : $300.33 Bulk	Bulk	Active	20-DIP	Through Hole	-	Identity Comparator	0°C ~ 70°C	4.75V ~ 5.25V	40 mA	440µA, 12mA	20-PDIP	15ns @ 5V, 15pF	-	-	8	-
AM25LS2521/B2A IC COMPARATOR IDENTITY 8B 20CLCC Advanced Micro Devices Datasheet	3,400 Marketplace	11 : $302.83 Bulk	Bulk	Active	20-CLCC	Surface Mount	-	Identity Comparator	-55°C ~ 125°C	4.5V ~ 5.5V	40 mA	440µA, 12mA	20-CLCC	15ns @ 5V, 15pF	-	-	8	-
PAL16R6B-2MW/883B PAL16R6 - ELECTRICALLY ERASABLE Advanced Micro Devices Datasheet	111 Marketplace	8 : $333.52 Bulk	Bulk	Obsolete	20-CFlatPack	Surface Mount	-	-	-	-	-	-	20-CFlatPack	-	-	-	-	-
5962-89841023A PAL22V10 - EE PAL DEVICE Advanced Micro Devices Datasheet	3,564 Marketplace	4 : $309.48 Bulk	Bulk	Active	28-CLCC	Surface Mount	-	-	-	-	-	-	28-CLCC (11.43x11.43)	-	-	-	-	-
AM29863PC IC TXRX NON-INV 5.5V 24DIP Advanced Micro Devices Datasheet	23,232 Marketplace	84 : $303.24 Bulk	Bulk	Obsolete	24-DIP (0.300", 7.62mm)	Through Hole	-	-	0°C ~ 70°C (TA)	4.5V ~ 5.5V	-	24mA, 48mA	24-PDIP	-	-	-	-	-
5962-89841053A PAL22V10 - EE PAL DEVICE Advanced Micro Devices Datasheet	4,920 Marketplace	7 : $313.53 Bulk	Bulk	Active	28-CLCC	Surface Mount	-	-	-	-	-	-	28-CLCC	-	-	-	-	-
5962-8984104KA PAL22V10 - EE PAL DEVICE Advanced Micro Devices Datasheet	1,499 Marketplace	4 : $300.44 Bulk	Bulk	Active	24-CFlatPack	Surface Mount	-	-	-	-	-	-	24-CFlatPack	-	-	-	-	-
AM29C853/BLA IC TXRX NON-INVERT 5.5V 24CDIP Advanced Micro Devices Datasheet	2,287 Marketplace	10 : $308.90 Bulk	Bulk	Active	24-CDIP (0.300", 7.62mm)	Through Hole	-	-	-55°C ~ 125°C (TA)	4.5V ~ 5.5V	-	15mA, 24mA	24-CDIP	-	-	-	-	-
AM29C833/B3A IC TXRX NON-INVERT 5.5V 28CLCC Advanced Micro Devices Datasheet	1,102 Marketplace	42 : $304.08 Bulk	Bulk	Active	28-CLCC	Surface Mount	-	-	-55°C ~ 125°C (TA)	4.5V ~ 5.5V	-	15mA, 24mA	28-CLCC (11.43x11.43)	-	-	-	-	-
