Coaxial Cables (RF)

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Length	Wire Gauge	Jacket (Insulation) Material	Conductor Strand	Cable Group	Operating Temperature	Cable Type	Jacket (Insulation) Diameter	Usage	Dielectric Material	Shield Coverage	Shield Material	Shield Type	Conductor Material	Jacket Color	Dielectric Diameter	VoP, Velocity of Propagation	Impedance	Spool Size
SUCOFORM_86 CABLE COAXIAL RG403 METER Huber+Suhner Datasheet	139 In Stock	1 : $14.32 3 : $39.63 5 : $63.60 7 : $87.08 10 : $121.60 25 : $285.00 50 : $542.00 100 : $1,029.00 Digi-Spool®, Continuous Spool	Sucoform	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	-	Solid	RG-403	-65°C ~ 165°C	Coaxial	-	-	Polytetrafluoroethylene (PTFE)	100%	Copper, Tinned	Braid	Steel, Copper Covered, Silver Coated	-	0.065" (1.65mm)	71	50 Ohms	328.1' (100.0m)
ENVIROFLEX_142 CABLE COAXIAL RG142 METER Huber+Suhner Datasheet	148 In Stock	1 : $18.09 3 : $50.04 5 : $80.35 7 : $110.04 10 : $153.70 25 : $360.00 50 : $685.00 100 : $1,299.00 Digi-Spool®, Continuous Spool	Enviroflex	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	RADOX®	Solid	RG-142	-40°C ~ 105°C	Coaxial	0.197" (5.00mm)	-	Foam Polyethylene, Cross Linked (SPEX)	95%, 97%	Copper, Silver Coated	Double Braid	Copper, Silver Coated	Black, Blue Stripe	0.116" (2.95mm)	70.9	50 Ohms	328.1' (100.0m)
G_02232_D CABLE COAXIAL RG174 METER Huber+Suhner Datasheet	552 In Stock	1 : $9.53 3 : $26.34 5 : $42.35 7 : $58.03 10 : $80.70 25 : $189.50 50 : $359.50 100 : $688.00 Digi-Spool®, Continuous Spool		Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	Poly-Vinyl Chloride (PVC)	-	RG-174	-	Coaxial	0.122" (3.10mm)	-	-	-	-	Double Braid	-	Black	-	-	50 Ohms	-
RADOX_RF_316_D CABLE COAXIAL RG316 METER Huber+Suhner Datasheet	235 In Stock	1 : $14.51 3 : $40.14 5 : $64.45 7 : $88.27 10 : $123.30 25 : $288.75 50 : $549.50 100 : $1,042.00 Digi-Spool®, Continuous Spool	Radox	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	RADOX®	-	RG-316	-40°C ~ 105°C	Coaxial	0.126" (3.20mm)	-	Foam Polyethylene, Cross Linked (SPEX)	90%, 96%	Copper, Silver Coated	Double Braid	Steel, Copper Covered, Silver Coated	Black	0.060" (1.52mm)	70.1	50 Ohms	328.1' (100.0m)
MULTIFLEX_141 CABLE COAXIAL RG402 METER Huber+Suhner Datasheet	299 In Stock	1 : $42.60 3 : $118.23 5 : $190.20 7 : $259.91 10 : $362.20 25 : $848.50 50 : $1,606.00 100 : $3,075.00 Digi-Spool®, Continuous Spool	Multiflex	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	Fluorinated Ethylene-Propylene (FEP)	Solid	RG-402	-	Coaxial	0.163" (4.14mm)	-	-	-	-	Foil, Braid	-	Blue	-	-	50 Ohms	-
RG_223_/U CABLE COAXIAL RG223 METER Huber+Suhner Datasheet	275 In Stock	1 : $12.95 3 : $35.82 5 : $57.50 7 : $78.75 10 : $110.00 25 : $257.75 50 : $490.50 100 : $930.00 Digi-Spool®, Continuous Spool		Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	Poly-Vinyl Chloride (PVC)	Solid	RG-223	-25°C ~ 85°C	Coaxial	0.213" (5.40mm)	-	Polyethylene (PE)	94%, 96%	Copper, Silver Coated	Double Braid	Copper, Silver Coated	Black	0.116" (2.95mm)	66	50 Ohms	328.1' (100.0m)
SUCOFORM_141_CU CABLE COAXIAL RG402 METER Huber+Suhner Datasheet	525 In Stock	1 : $17.19 3 : $47.58 5 : $76.35 7 : $104.58 10 : $146.10 25 : $342.25 50 : $651.00 100 : $1,235.00 Digi-Spool®, Continuous Spool	Sucoform	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	-	Solid	RG-402	-65°C ~ 165°C	Coaxial	-	-	Polytetrafluoroethylene (PTFE)	100%	Copper, Tinned	Braid	Copper, Silver Coated	-	0.116" (2.95mm)	71	50 Ohms	328.1' (100.0m)
K_02252_D CABLE COAXIAL RG316 METER Huber+Suhner Datasheet	390 In Stock	1 : $20.42 3 : $56.55 5 : $91.15 7 : $124.67 10 : $172.90 25 : $406.25 50 : $771.00 100 : $1,469.00 Digi-Spool®, Continuous Spool		Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	Fluorinated Ethylene-Propylene (FEP)	-	RG-316	-	Coaxial	0.118" (3.00mm)	-	-	-	-	Double Braid	-	Brown	-	-	50 Ohms	-
RG_316_/U CABLE COAXIAL RG316 METER Huber+Suhner Datasheet	878 In Stock	1 : $11.51 3 : $31.86 5 : $51.10 7 : $70.00 10 : $97.80 25 : $229.00 50 : $436.00 100 : $827.00 Digi-Spool®, Continuous Spool		Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	Fluorinated Ethylene-Propylene (FEP)	-	RG-316	-	Coaxial	0.098" (2.48mm)	-	-	-	-	Braid	-	Brown	-	-	50 Ohms	-
SUCOFORM_141 CABLE COAXIAL RG402 METER Huber+Suhner Datasheet	108 In Stock	1 : $17.19 3 : $47.58 5 : $76.35 7 : $104.58 10 : $146.10 25 : $342.25 50 : $651.00 100 : $1,235.00 Digi-Spool®, Continuous Spool	Sucoform	Digi-Spool®, Continuous Spool	Active	-	Enter Number of Meters in Order Quantity	-	-	Solid	RG-402	-65°C ~ 165°C	Coaxial	-	-	Polytetrafluoroethylene (PTFE)	99%	Copper, Tinned	Braid	Steel, Copper Covered, Silver Coated	-	0.116" (2.95mm)	71	50 Ohms	328.1' (100.0m)
