10DAW4_4803S1.5 _ DC DC Converters_Power Supplies

Part Number	10DAW4_4803S1.5
Manufacturer	GAPTEC Electronic
Other Part Numbers	3182-10DAW4_4803S1.5-ND 3182-10DAW4_4803S1.5
Description	ISOLATED MODULE DC DC CONVERTERS
Detailed Description	Isolated Module DC DC Converter 1 Output 3.3V 2.4A 18V - 72V Input
Manufacturer Standard Lead Time	9 weeks
Datasheet	Datasheet

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		GAPTEC Electronic
Series		10DAW4_1.5 (10W)
Packaging		Tube
Part Status		Active
Package / Case		6-DIP Module, 5 Leads
Size / Dimension		2.00" L x 1.00" W x 0.46" H (50.8mm x 25.4mm x 11.8mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 85°C (With Derating)
Applications		ITE (Commercial)
Voltage - Input (Max)		72V
Approval Agency		CE
Efficiency		79%
Current - Output (Max)		2.4A
Voltage - Input (Min)		18V
Voltage - Output 1		3.3V
Power (Watts)		7.92 W
Number of Outputs		1
Voltage - Isolation		1.5 kV

RESOURCE TYPE		LINK
Datasheets		10DAW4_4803S1.5

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Affected
RoHS Status		RoHS Compliant
