PUC1215090D2BG _ DC DC Converters_Power Supplies

Part Number	PUC1215090D2BG
Manufacturer	Flex Power Modules
Other Part Numbers	2166-PUC1215090D2BG-ND 2166-PUC1215090D2BG
Description	15V -9V DC/DC CONVERTERS ISOLATE
Detailed Description	Isolated Module DC DC Converter 2 Output 15V -9V 100mA, 60mA 10.8V - 13.2V Input
Manufacturer Standard Lead Time	30 weeks
Datasheet	Datasheet

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Flex Power Modules
Series		PUC-D2BG (2W)
Packaging		Tube
Part Status		Active
Package / Case		7-SIP Module, 5 Leads
Size / Dimension		0.77" L x 0.39" W x 0.49" H (19.5mm x 9.8mm x 12.5mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 100°C
Applications		ITE (Commercial)
Voltage - Input (Max)		13.2V
Approval Agency		cURus, UL
Efficiency		81%
Current - Output (Max)		100mA, 60mA
Voltage - Input (Min)		10.8V
Voltage - Output 1		15V
Voltage - Output 2		-9V
Power (Watts)		2.04 W
Number of Outputs		2
Voltage - Isolation		6.2 kV
Standard Number		60950-1; 62368-1

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
